SD Series |
SD46-1 |
SD34-1 |
SD22-1 |
|
Input Voltage (V) |
220 |
220 |
220 |
|
Power (W) |
4000 |
2200 |
1500 |
|
Operating Current (A) |
18 |
10 |
7 |
|
Peak Temperature (°C) |
350 |
350 |
500 |
|
Temperature Control Accuracy (°C) |
±0.5 |
±0.5 |
±0.5 |
|
Temperature Control Method |
PID |
PID |
PID |
|
Main Heating Zone Dimensions (mm) |
595×385 |
390*298 |
200*200 |
|
Auxiliary Heating Zone Dimensions (mm) |
400×60×2+710×60×2 |
300×60×2+510×60×2 |
320×60×2+200×60×2 |
|
Furnace Dimensions (L×W×H) mm |
710×640×140 |
525×560×140 |
440×320×140 |
|
Control Box Dimensions (L×W×H) mm |
220×420×145 |
220×420×145 |
None |
|
Weight (KG) |
46 |
27 |
13 |
