Temperature Controller
|
No letter: single segment program temperature control digital display;
Type B: program temperature control digital display
|
|
Operating Functions
|
No letter: fixed value operation;
Type B: fixed value operation, program operation
|
|
Program Mode
|
No letter: single segment operation;
Type B: program operation with 2 curves and 30 steps
|
|
Safety Devices
|
Overcurrent leakage protection switch
|
|
ML 1200°C
|
ML212/212B
|
ML712/712B
|
ML1612/1612B
|
ML2412/2412B
|
ML3612/3612B
|
|
Furnace Material
|
Polycrystalline Mullite Fiber
|
|
Heater
|
Nickel-Chromium-Aluminum Alloy
|
|
Temperature Range
|
300-1200°C
|
|
Temperature Rising Time
|
≤30 Minutes
|
|
Temperature Control Accuracy
|
±1°C
|
|
Temperature Resolution
|
1°C
|
|
Furnace Dimensions (mm)
|
120×200×80
|
200×300×120
|
250×400×160
|
300×400×200
|
300×400×300
|
|
Volume
|
2L
|
7L
|
16L
|
24L
|
36L
|
|
Power Supply Voltage
|
220V
|
220V
|
220V
|
380V
|
380V
|
|
Rated Power
|
1.5KW
|
3KW
|
6KW
|
6.6KW
|
10KW
|
|
Overall Dimensions (mm)
|
480×617×683
|
560×709×723
|
630×808×783
|
650×813×818
|
650×818×918
|
|
Packaging Dimensions (mm)
|
650×760×790
|
720×870×850
|
790×970×910
|
810×960×945
|
810×960×1045
|
|
Net Weight / Gross Weight
|
40/45KG
|
60/65KG
|
80/86KG
|
90/98KG
|
100/110KG
|
|
ML 1400°C
|
ML314/314B
|
ML814/814B
|
ML1214/1214B
|
ML1814/1814B
|
ML2714/2714B
|
ML3614/3614B
|
|
Furnace Material
|
Polycrystalline Mullite Fiber
|
|
Heater
|
Silicon Carbide Rod
|
|
Temperature Range
|
300-1400°C
|
|
Temperature Rising Time
|
≤35 Minutes
|
|
Temperature Control Accuracy
|
±1°C
|
|
Temperature Resolution
|
1°C
|
|
Furnace Dimensions (mm)
|
150×200×100
|
180×250×180
|
200×300×200
|
250×300×250
|
300×300×300
|
300×400×300
|
|
Volume
|
3L
|
8L
|
12L
|
18L
|
27L
|
36L
|
|
Power Supply Voltage
|
220V
|
220V
|
380V
|
380V
|
380V
|
380V
|
|
Rated Power
|
3KW
|
4KW
|
6KW
|
8KW
|
12KW
|
14KW
|
|
Overall Dimensions (mm)
|
520×660×813
|
550×698×893
|
570×749×911
|
620×749×963
|
670×760×1031
|
670×849×1033
|
|
Packaging Dimensions (mm)
|
680×785×1040
|
710×835×1120
|
730×885×1140
|
780×885×1190
|
830×885×1260
|
830×985×1260
|
|
Net Weight / Gross Weight
|
40/50KG
|
60/70KG
|
70/85KG
|
80/95KG
|
90/105KG
|
100/115KG
|
|
ML 1600°C
|
ML216/216B
|
ML416/416B
|
ML816/816B
|
|
Furnace Material
|
Polycrystalline Mullite Fiber
|
|
Heater
|
Molybdenum Disilicide Heating Element
|
|
Temperature Range
|
300-1600°C
|
|
Exhaust Vent
|
Inner diameter: 18mm; Outer diameter: 22mm
|
|
Temperature Rising Time
|
≤50 Minutes
|
|
Temperature Control Accuracy
|
±1°C
|
|
Temperature Resolution
|
1°C
|
|
Furnace Dimensions (mm)
|
90×150×150
|
150×150×150
|
150×300×150
|
|
Volume
|
2L
|
4L
|
8L
|
|
Power Supply Voltage
|
220V
|
380V
|
|
Power
|
3KW
|
6KW
|
9KW
|
|
Overall Dimensions (mm)
|
600×762×1102
|
600×871×1102
|
|
Packaging Dimensions (mm)
|
760×885×1310
|
760×985×1310
|
|
Net Weight / Gross Weight
|
70/90KG
|
80/100KG
|
110/130KG
|
